| Genset Specifications | |
| Engine Brand/Type | JIANGXI ISUZU / JE493ZDB-04 |
| Alternator Brand Type | RODICO / RP184G |
| Control Module | DSE 4520 |
| Circuit Breaker Type (Standard) | 3 Pole MMCB |
| Fuel Cons (L/h) 100% Load | 6.2 L |
| Fuel Tank Capacity (L) | – |
| Dimension (mm) | 2000 x 890 x 1120 mm |
| Weight (Kg) | 730 |
| Engine Specifications | |
| Induction System | Turbocharger |
| Number of Cylinder | 4 |
| Bore x Stroke | 93 x 102 |
| Displacement (L) | 2.771 |
| Cooling System | Water |
| Gross Engine Power (kW) | 28 |
| Prime Power (kVA) | 30 |
| Governor | Electrical |
| Oil Capacity (L) | 5.6 |
| Coolant Capacity (L) | 10 |
| Alternator Specifications | |
| Rated Capacity (kVA) | 30 |
| Phase | 3 |
| Volts | 400 |
| Amps | 43.3 |
| Bearing | Single |
| Windings | 100% Copper |
| Rating | CONT |
| Enclosure | IP23 |
| Insulation Class | H |
| Excitor type | Self Excitation |
