| Genset Specifications | |
| Engine Brand/Type | RODICO / R4108IZLD |
| Alternator Brand Type | RODICO / KAL224K4 |
| Control Module | DSE 4520 / HGM 6120 N |
| Circuit Breaker Type (Standard) | 3 Pole MMCB |
| Fuel Cons (L/h) 100% Load | 18.5 L |
| Fuel Tank Capacity (L) | 122 L |
| Dimension (mm) | 2400 x 1000 x 1330 mm |
| Weight (Kg) | 1226 kg |
| Engine Specifications | |
| Induction System | Turbocharged |
| Number of Cylinder | 6 |
| Bore x Stroke | 105×135 |
| Displacement (L) | 4.5 |
| Cooling System | Water |
| Gross Engine Power (kW) | 88 |
| Prime Power (kVA) | 85 |
| Governor | Manual |
| Oil Capacity (L) | 16 |
| Coolant Capacity (L) | 10 |
| Alternator Specifications | |
| Rated Capacity (kVA) | 85 |
| Phase | 3 |
| Volts | 380 |
| Amps | 129.1 |
| Bearing | Single |
| Windings | 100% Copper |
| Rating | S1 |
| Enclosure | IP23 |
| Insulation Class | H |
| Excitor type | Self Excitation |
